Installing a Nest thermostat is one of the most convenient ways to improve the everyday schedule of your comfort system. This smart thermostat can recognize your preferences and automatically make changes. But as you may expect, it won’t work well or at all if you see an error code show up. The specific error code offers useful information about the underlying problem, something a trained technician can use to provide solutions that much quicker.
Here are seven of the most likely error codes you may encounter on your Nest thermostat. We’ll walk you through the basics of each error code on top of how you might address it and the estimated cost to do so. Remember that while the investment will ultimately depend on the precise Nest model, you can expect to pay between $75-$200 for repairs. This should include things like travel and labor costs on top of any specific parts necessary to wrap up repairs.
e298 – Critical
This critical error code is limited to newer models of the Nest thermostat and is displayed when the power is disconnected from the system. Since this is a critical power error, the thermostat will change to the backup battery system. The error message will remain on display until the problem is fixed.
Losing power to your Nest thermostat can be for a number of reasons. The wiring could have disconnected or become damaged, or a disconnection may have appeared further along in the electrical system. This could be the circuit breaker, fuse box or system switch. A certified technician will inspect electrical connections and wiring until they uncover the source of the problem.
e294 – Critical
Critical error code e294 is displayed when your Nest thermostat’s wiring has to be reconfigured. More specifically, the technician should reconfigure the R wire. They’ll first complete a factory reset of your thermostat to ensure it’s not merely a software issue. If that doesn’t work, they’ll examine the wiring diagram of the thermostat and begin inspecting connectors.
They’ll detach the power and slowly inspect each wire, ensuring they are fully placed into the connector with the correct amount of exposed copper. After they find the malfunctioning connector, it can be swapped for a new one.
e195 – Critical
This critical error code can appear when the weather outside is especially hot. The HVAC system can break down and stop giving power to your Nest thermostat. When this problem persists, the backup battery in your thermostat drains and the thermostat will finally turn off. In the event the breakers are on, you can check a handful of other places before contacting a professional technician.
As this error can deplete your thermostat’s battery, the first step may be providing enough power to determine if this specific error code is what you’re dealing with. You can disconnect the thermostat from its base and deliver power with a USB cable. In the event it presents error code 195, you should continue to visually check components including the wiring as well as your air conditioner’s air filter or drainage system. If you struggle to uncover anything wrong with these components, it’s maybe best to call a pro.
e103 – Critical
Another critical error code, e103 signifies an electrical problem with your Nest thermostat. More specifically, e103 will refer to an overcurrent problem, which means the wiring is receiving more power than needed. This can stem from the breaker box, an error from the control board or because of a bad connection in the thermostat. Your technician will meticulously investigate and test the Nest’s electrical system to figure out where the power is surging or why the thermostat is convinced there’s an overcurrent problem.
n260
Even though this error code isn’t critical, it could still keep you from using the Nest thermostat how you prefer to. Error code n260 concerns the lack of a C wire or Nest Power Connector, as the absence of one can block your Nest from obtaining adequate power. You can inspect the Nest’s C connector for the presence of a C wire and modify the wiring itself if there is. If not, you’ll need a Nest Power Connector.
With installation of a Nest Power Connector, you will sometimes notice error code E297 be displayed. This can be dealt with by updating your thermostat in Settings -> Software -> Update. If the Power Connector is already installed, you’ll instead need to update the wiring info in the app from Settings -> Thermostat -> Wiring -> Update wiring.
e104 – Critical
Just like error code e103, e104 is a critical error stemming from an overcurrent. If excessive power is sent through the Nest’s wiring, it can damage internal components and could even be a fire hazard. If you notice this error code pop up on your Nest thermostat and want to protect from electrical damage, it’s suggested to switch the power off as soon as you can. You can then get in touch with a professional technician with the proper experience identifying and resolving electrical issues.
e73 – Critical
When your thermostat displays error code e73, it indicates that the Rc wire is not receiving power.
This might be as straightforward as the breaker being switched off, but it could also be an issue with the wiring. After shutting off the power to your HVAC system and thermostat, you can visually inspect the wires to make sure they’re not loose or damaged. If nothing seems to be out of place, it’s time to get in touch with a local professional.
